OVERHEAD LINE PRODUCT SYSTEM

Oil-Immersed Distribution & Power Transformers

Oil-immersed distribution and power transformers for utility networks, industrial plants and substations. Request a quotation with the transformer schedule, single-line diagram and site data. Specify rated power, HV/LV voltages, phase and frequency, vector group, impedance, tap range and tap-changer type, guaranteed loss limits, insulation level, temperature rise, cooling method, mounting arrangement, oil requirement, bushings or cable boxes, protection and monitoring accessories. Include altitude, ambient temperature, seismic or pollution conditions, transport limits and required tests. Distribution and large power transformers use different design and test scopes. Capacity, losses, efficiency, short-circuit withstand, sound level, temperature rise and IEC/IEEE/GB compliance must be supported by documents for the exact offered unit. Compare distribution transformers and power and substation transformers before final selection.

Request quotation →Prepare your BOM
TECHNICAL OVERVIEW

Selected as a system, not as an isolated item.

Selection is based on rated power, HV and LV voltage, vector group, impedance, losses, tap range, cooling, insulation level and approved project tests. The current catalogue covers oil-immersed distribution units up to 36 kV and a 120 MVA industrial substation power-transformer reference.

KOVYEL PRODUCT CATALOGUE

Explore real product families.

Open a product family to review applications, representative model ranges and the data needed for selection.

PRODUCT RANGE

Typical supply scope.

06

Industrial substation power transformers up to 120 MVA

Add to RFQ →
APPLICATIONS

Where this system is used.

  • Rural electrification
  • Urban distribution
  • Industrial distribution feeders
  • Line extension projects
RFQ INPUTS

Information needed for matching.

  1. 1Rated power and phases
  2. 2HV and LV voltage
  3. 3Vector group and frequency
  4. 4Impedance and loss requirement
  5. 5Tap range
  6. 6Accessories, tests and environment
STANDARDS & SPECIFICATIONS

Confirmed item by item.

Final compliance depends on the approved project specification, drawings, voltage class, test requirements and destination utility.

IEC 60076Approved transformer test scheduleIEEE / ANSI requirementsEnergy-efficiency requirementApproved utility specification
BUYER QUESTIONS

Direct technical answers.

Can transformers be included with the complete line BOQ?

Yes. Transformer items can be coordinated with poles, mounting steelwork, arresters, fuse cutouts, connectors, grounding and LV accessories.

Are transformer values finalized from capacity alone?

No. Voltage ratio, vector group, impedance, losses, tap range, insulation level, accessories, environment and testing must also be confirmed.

Separate transformer construction and installation

Choose the transformer function and installation arrangement before comparing capacity. Distribution, substation and special industrial transformer requirements belong to their respective schedules.

Include these fields in your RFQ

Send itemised quantities with the relevant drawing or technical schedule. The quotation should identify the offered model, included accessories and any unresolved selection inputs.

Request a quotation for Oil-Immersed Distribution & Power Transformers

PRODUCT RANGE AND PROCUREMENT

Continue your selection and quotation review.

Have a BOQ, drawing or technical specification?

Send the project basics for a coordinated supply proposal.

Start project inquiry →
