OVERHEAD LINE PRODUCT SYSTEM

Overhead Line Insulators

Composite, porcelain and glass insulators for overhead distribution, transmission, substations and equipment connections. Request a quotation with the insulator schedule, string drawing and service conditions. Select suspension, strain, pin, line-post, station-post, shackle, spool or equipment insulators by system and equipment voltage, insulation level, required creepage distance, pollution severity, mechanical load, coupling or mounting interface, string geometry, housing/material, altitude and environmental conditions. Review insulator pins and pole-top pins, porcelain and glass suspension/strain insulators and composite suspension/tension insulators according to the required function. Electrical and mechanical ratings, creepage, ageing, pollution performance and IEC/ANSI compliance must be supported by documents and tests for the exact offered model and assembly.

Request quotation →Prepare your BOM
TECHNICAL OVERVIEW

Selected as a system, not as an isolated item.

Insulator selection is matched to system voltage, highest equipment voltage, mechanical load, creepage distance, pollution level, fitting interface and project standard. Complete strings can include hardware, arcing devices and grading components.

Find the insulator family that matches the support or termination

Start with how the conductor or equipment is supported, then define the electrical, mechanical and mounting requirements. Different insulator families should not be compared by voltage label alone.

Selection pointWhat the purchase specification should identify
Suspension or tension stringComposite suspension and tension insulators or porcelain and glass suspension/strain insulators — match the assembly duty, coupling and specified performance.
Pin, line-post or station supportPin, post, station and crossarm insulators — provide the support arrangement, electrical requirements, mechanical duty and mounting drawing.
Shackle or spool supportShackle and spool insulators — identify the conductor arrangement and the required mounting hardware.
Equipment or specialty interfaceEquipment and specialty insulators — submit the equipment drawing and dimensional interface before model selection.

Request the data sheet, dimensioned drawing and specified acceptance documents for the chosen model. The catalogue family helps locate products; it does not replace the approved technical specification.

KOVYEL PRODUCT CATALOGUE

Explore real product families.

Open a product family to review applications, representative model ranges and the data needed for selection.

PRODUCT RANGE

Typical supply scope.

APPLICATIONS

Where this system is used.

  • Distribution poles
  • Steel-pole lines
  • Lattice transmission towers
  • Coastal, desert and polluted environments
RFQ INPUTS

Information needed for matching.

  1. 1Nominal and highest system voltage
  2. 2Insulator material preference
  3. 3Mechanical failing load
  4. 4Creepage distance
  5. 5Coupling designation
  6. 6Pollution and altitude conditions
STANDARDS & SPECIFICATIONS

Confirmed item by item.

Final compliance depends on the approved project specification, drawings, voltage class, test requirements and destination utility.

IEC 61109IEC 60383IEC 62217ANSI / IEEE requirementsApproved utility drawings
BUYER QUESTIONS

Direct technical answers.

How is the required creepage distance confirmed?

It is reviewed against the specified pollution severity, insulation material, system voltage and the utility or project requirement.

Can complete insulator strings be supplied?

Yes. Insulators, yoke plates, shackles, arcing horns, grading rings and conductor clamps can be coordinated as an approved string assembly.

PRODUCT RANGE AND PROCUREMENT

Continue your selection and quotation review.

Have a BOQ, drawing or technical specification?

Send the project basics for a coordinated supply proposal.

Start project inquiry →
