JUMPER SUSPENSION CLAMP · CATALOGUE-BACKED RANGE
XCS Jumper Suspension Clamps
XCS jumper suspension clamps control and support jumper conductors at strain towers, terminal structures and substation interfaces without imposing full line tension on the jumper.
AVAILABLE RANGE
Representative product families.
Final model selection is confirmed against the approved conductor, equipment interface, drawings and project specification.
Single-jumper XCS arrangementsTwin-jumper support variantsClevis-linked clamp bodiesProject-matched conductor grooves
APPLICATIONS
Built for real line interfaces.
- Strain-tower jumpers
- Terminal-tower jumpers
- Substation gantry connections
- Twin-bundle jumper support
KEY FEATURES
What the product family covers.
- Low-stress conductor support
- Bolted keeper and saddle construction
- Flexible string attachment
- Single and twin-jumper configurations
SELECTION DATA
Send these details for a matched quotation.
- 01Jumper conductor type
- 02Conductor diameter
- 03Single or twin arrangement
- 04Support-string geometry
- 05Required movement range
- 06Approved jumper drawing
TECHNICAL BASIS
Confirmed before supply.
Standards, drawings, dimensions and test requirements are reviewed item by item. Catalogue model references are not a substitute for the approved project specification.
IEC 61284 where specifiedApproved jumper arrangementCatalogue model data
