DL JBK 12/24 kV 630 A Shielded Back Connector
Separable Cable Connectors & Bushings · Drawing-confirmed project supply
KOVYEL DL JBK shielded back connectors extend 630 A cable circuits from a compatible fore-connector with a fully screened and sealed interface.
Selection begins with the actual project interface.
KOVYEL DL JBK shielded back connectors extend 630 A cable circuits from a compatible fore-connector with a fully screened and sealed interface.
KOVYEL confirms final selection against the approved drawing, interface dimensions, service conditions and purchase specification before quotation and supply. Catalogue references define the product family; the approved project documents remain the controlling basis.
Review the available construction and product views.
Images show representative configurations. Final construction, marking and packing are confirmed against the approved project documents.
The information buyers need before model confirmation.
Verified catalogue data is shown below. Dimensions, ratings and interfaces that depend on the project remain subject to the approved drawing and purchase specification.
| Product | DL JBK 12/24 kV 630 A Shielded Back Connector |
|---|---|
| Category | Separable Cable Connectors & Bushings |
| Representative range / models | DL JBK-12/630 and DL JBK-24/630 |
| Standards / reference basis | Catalogue technical data and project requirements confirmed by KOVYEL before supply |
| Typical applications | Connection of polymeric cable to transformers and switchgear; Indoor and outdoor medium-voltage installations; Cable branch boxes, motors and distribution equipment |
| System voltage | 12 or 24 kV |
| Continuous current | 630 A |
| 12 kV conductor range | 25-500 mm² |
| 24 kV conductor range | 35-400 mm² |
| Cable insulation | XLPE, EPR or equivalent polymeric insulation |
| Mounting | Vertical, horizontal or any intermediate angle |
| Connection requirement | Used behind a compatible fore-connector; not connected directly to an apparatus bushing |
| Final dimensions and ratings | Confirmed against the approved drawing, equipment interface and project specification |
| Supply basis | Project-specific RFQ, coordinated documentation and export packing |
Unverified dimensions or performance ratings are not published as fixed values. Submit the controlling drawing or requirement schedule for final confirmation.
Where this product family is typically used.
Connection of polymeric cable to transformers and switchgear
Expandable rear connection for additional branches
Indoor and outdoor medium-voltage installations
Fully screened and submersible assembly
Cable branch boxes, motors and distribution equipment
Built-in capacitive test point
