CONTROL CABLE · CATALOGUE-BACKED RANGE
Control & Instrumentation Cables
Multi-core control and instrumentation cables for measurement, signalling and auxiliary control systems.
AVAILABLE RANGE
Representative product families.
Final model selection is confirmed against the approved conductor, equipment interface, drawings and project specification.
Numbered multi-core control cableOverall screened constructionIndividual and overall screening optionsArmoured and unarmoured constructions
APPLICATIONS
Built for real line interfaces.
- Substation control systems
- Protection and metering circuits
- Industrial automation
- Equipment interconnection
KEY FEATURES
What the product family covers.
- Core identification and conductor options
- Copper-tape or braided screen options
- PVC or low-smoke sheath options subject to specification
- Construction coordinated with signal and environmental requirements
SELECTION DATA
Send these details for a matched quotation.
- 01Core count and conductor size
- 02Voltage rating
- 03Screening arrangement
- 04Armour requirement
- 05Fire-performance requirement
- 06Installation environment
TECHNICAL BASIS
Confirmed before supply.
Standards, drawings, dimensions and test requirements are reviewed item by item. Catalogue model references are not a substitute for the approved project specification.
GB/T 9330 where specifiedIEC 60227 where applicableIEC 60332 fire-performance options
