INSULATOR-STRING LOAD-DISTRIBUTION PLATE · CATALOGUE-BACKED RANGE
Yoke Plates & Link Plates
Yoke plates and link plates distribute mechanical loads across single, twin and multiple insulator strings and coordinate the attachment of bundled-conductor fittings.
AVAILABLE RANGE
Representative product families.
Final model selection is confirmed against the approved conductor, equipment interface, drawings and project specification.
Triangular yoke platesRectangular link platesTwin-string yoke assembliesBundle-count matched plate arrangements
APPLICATIONS
Built for real line interfaces.
- Twin and multiple insulator strings
- Bundled-conductor tension strings
- Suspension string assemblies
- Transmission-tower hardware sets
KEY FEATURES
What the product family covers.
- Hole geometry matched to the complete string
- Hot-dip galvanized plate steel
- Single- and multi-string configurations
- Mechanical load coordinated across all attachment points
SELECTION DATA
Send these details for a matched quotation.
- 01String configuration
- 02Bundle count
- 03Required mechanical strength
- 04Hole diameters and centres
- 05Connected fitting types
- 06Approved assembly drawing
TECHNICAL BASIS
Confirmed before supply.
Standards, drawings, dimensions and test requirements are reviewed item by item. Catalogue model references are not a substitute for the approved project specification.
IEC 61284 where specifiedApproved insulator-string drawingCatalogue dimensional data
