TRUNNION SUSPENSION CLAMP · CATALOGUE-BACKED RANGE
XGU & XGF Overhead Conductor Suspension Clamps
XGU and XGF suspension clamps support bare overhead conductors at tangent structures while allowing controlled conductor movement and a project-matched connection to the insulator string.
AVAILABLE RANGE
Representative product families.
Final model selection is confirmed against the approved conductor, equipment interface, drawings and project specification.
XGU standard suspension clampsXGF high-strength variantsClevis and socket-linked arrangementsArmour-rod compatible conductor saddles
APPLICATIONS
Built for real line interfaces.
- Tangent transmission towers
- Distribution suspension structures
- River and road crossing approaches
- Substation bus and gantry support
KEY FEATURES
What the product family covers.
- Smooth conductor-support groove
- Hot-dip galvanized structural hardware
- Aluminium-alloy conductor contact options
- Attachment geometry matched to the insulator string
SELECTION DATA
Send these details for a matched quotation.
- 01Conductor type and diameter
- 02Vertical and longitudinal load
- 03Line deviation angle
- 04Insulator-string connection
- 05Armour rod requirement
- 06Corrosion class
TECHNICAL BASIS
Confirmed before supply.
Standards, drawings, dimensions and test requirements are reviewed item by item. Catalogue model references are not a substitute for the approved project specification.
IEC 61284 where specifiedApproved line-hardware drawingCatalogue model data
