U-Type Shackles & Clevis Links
U-type shackles and clevis links connect insulator strings, yoke plates and line fittings while providing project-matched mechanical strength and articulation.
AVAILABLE RANGE
Representative product families.
Final model selection is confirmed against the approved conductor, equipment interface, drawings and project specification.
U-type shacklesClevis-clevis linksClevis-tongue linksPin and cotter retention options
APPLICATIONS
Built for real line interfaces.
- Suspension insulator strings
- Tension insulator strings
- Yoke-plate assemblies
- Tower attachment points
KEY FEATURES
What the product family covers.
- Forged steel construction
- Hot-dip galvanized finish
- Matched pin and opening dimensions
- Mechanical class coordinated across the string
SELECTION DATA
Send these details for a matched quotation.
- 01Required ultimate mechanical strength
- 02Connection type at both ends
- 03Pin diameter
- 04Opening and overall dimensions
- 05String assembly drawing
- 06Corrosion requirement
TECHNICAL BASIS
Confirmed before supply.
Standards, drawings, dimensions and test requirements are reviewed item by item. Catalogue model references are not a substitute for the approved project specification.
IEC 61284 where specifiedIEC 60372 interface coordination where applicableApproved string drawing
